API 7K Oil drilling MP Safety clamps,drill collar safety clamp API Safety Clamp
The Safety Clamp consists of individual links, flexibly hinged together.
Each link has a separate tapered slip which acts as a gripping member, much like a tapered rotary slip, and each slip is held in a retracted position on the taper by spring tension.
When the clamp is tightened, each small slip takes a firm initial grip on the surface of the pipe. Should the pipe start to fall, or should load increase occur against the slips, the taper mounting causes each slip to wedge tighter against the surface of the pipe to increase the grip or lock the pipe against further movement.
|
Type
|
Pipe O.D(in)
|
No. of Chain Links
|
|
MP-S
|
27/8-41/8
|
7
|
|
4-5
|
8
|
|
|
MP-R
|
41/2-55/8
|
7
|
|
51/2-7
|
8
|
|
|
63/4-81/4
|
9
|
|
|
8-91/4
|
10
|
|
|
91/4-101/2
|
11
|
|
|
MP-M
|
101/2-111/2
|
12
|
|
111/2-121/2
|
13
|
|
|
121/2-135/8
|
14
|
|
|
135/8-143/4
|
15
|
|
|
143/4-157/8
|
16
|
|
|
MP-L
|
157/8-17
|
17
|
|
17-181/2
|
18
|
|
|
181/8-193/8
|
19
|
|
|
MP-XL
|
193/8-203/8
|
19
|
|
203/8-211/2
|
20
|
|
|
21-225/8
|
21
|
|
|
225/8-233/4
|
22
|
|
|
233/4-247/8
|
23
|
|
|
247/8-26
|
24
|
|
|
26-271/8
|
25
|
|
|
293/8-301/2
|
28
|
|
|
35-361/8
|
33
|
Safety Clamps are necessary tools for handling drill collars; flush joint pipes and small shoulder pipes. They are designed and manufactured according to API Spec 7K.
There are three types of safety clamps: Type WA-T, WA-C and type MP.
Safety Clamps could adjust pipes to different sizes by changing the quantity of chain links, can accommodate pipes from 1.1/8 to 4.1/2inch.
Safety Clamps adopts multi-link design, which provides uniform pressure around the pipe to minimize the risks of crushing the pipe or damaging the surface. Each link, complete with the taper slip, is interchangeable as a unit.
Our company has been in the oil & gas drilling equipment industry for over more years, We are here to serve all your drilling equipment needs.
