Shale Shaker
Shale shaker is the latest solid control equipment developed by our company for oil drilling. It absorbs the design experience and advanced technology of similar products at home and abroad, adopts imported exciting motor, and is the most advanced vibrating screen in our country at present. Our company can manufacture double or triple vibrating screens suitable for drilling fluid purification according to customers’needs and provide phase.
• ZS752 series Mini shakers have been widely used in trench-less HDD, water well drilling, diamond core drilling etc., best option for compact system and low flow rate.
• ZS703 & ZS594 series single deck shale shaker is popular in oil gas drilling, big trench-less HDD projects, or other industry separation demand.
• ZS706 series double deck shaker is properly designed for piling, TBM, big oil gas rig, big trench-less project, or the industry separation for multi- phase separation.
| Model | ZS752F-MDZF | ZS703F-SDZF | ZS703F-SHBF | ZS594F-SHBF | ZS706F-SHBF |
|---|---|---|---|---|---|
| Vibration Mode | Linear Motion | ||||
| Capacity(m³/h) | 45(200GPM) | 120(528GPM) | 140(616GPM) | 140(616GPM) | |
| Vibration | 2×1.0 | 2×1.72 | 2×1.94 | ||
| Motor(Kw) | |||||
| Screen Qty(Pcs) | 2 | 3 | 4 | 6 | |
| Screen Size(mm) | 750×900 | 700×1250×29 | 585×1165×40 | Up:750×900 | |
| Down:700×1250 | |||||
| Screen Area(m2) | 1.35 | 2.63 | 2.73 | Up:2.03 | |
| Down:2.63 | |||||
| Adjustable G Force | ≤7.5G | ≤7.3G | |||
| Vibration | 4.14~5.96 | 4.04~5.82 | |||
| Amplitude(mm) | |||||
| Deck Angle Range | +2° | -1°~+5° | |||
| Feeding Type | Top Box Feeder | Weir Feeder | |||
| Weir Height(mm) | 714 | 1060 | 895 | ||
| EX Standard | ExdIIBt4 / IEC EX/ ATEX | ||||
| Weight(Kg) | 929 | 1665 | 1571 | 1624 | 1795 |
| L×W×H(mm) | 1816×1657×1083 | 2462×2007×1476 | 2744×1968×1435 | 2989×1968×1435 | 2744×1968×1435 |
| Remarks | Above capacity only for reference, actual capacity will be various as per screen API No. and mud conditions | ||||
Our company has been in the oil & gas drilling equipment industry for over more years, We are here to serve all your drilling equipment needs.
